Carbo Bakelite Sponge Polishing Wheel(CBS)

  • Description

With elastics and absorbability which is suit for mirror shining polishing operation of all kinds of grinding machine for example, tape recording magnetic head, all kinds of bearing pin, driving shaft in a compressor and all kinds of mold working.

  • Manual
  • With elastics and absorbability, the hardness can be adjusted with the additive, which gives a mutual consideration to polishing and cutting.
  • It is suited for mirror shining polishing operation of all kinds of grinding machine for example, tape-recording magnetic head, all kinds of bearing pin, driving shaft in a compressor and all kinds of mold working.


HSP (Heterogeneous Surface Polishing) CASE Study – for PCB backing
Parameter :
SPECIFICATION:HSP 220 180X13X31.75
COLLANT:soluble oil
WHEEL SPEED:3600 rpm
ROUGH INFEED:0.02 mm
FINISH INFEED:0.01 mm
CROSS FEED:3 mm

Features of Anchor HSP grinding wheel
  • 1. Improve yield rate   The special specification of HSP wheel could reduce the grinding force to avoid chip broken.
  • 2. High efficiency  Good cutting ability, reducing the dress frequency.
  • 3. Good surface roughness
  • 4. Size customize

Other Polishing Applied Cases of CBS Wheel
Catalog Download
